Servo motors with integrated electronics

esiMot - Servo motors with integrated electronics

Let us advise you

Servomotors with integrated electronics from esitron - series esiMot

Brushless servomotors (also known as permanent magnet motors or PM motors) are wear-free and maintenance-free, have a high degree of efficiency, high dynamic acceleration and are very robust.

esiMot micro

Rated power
26 - 105 W
Nominal torque
0,0625 - 0,25 Nm
Motor supply
24 V DC
Optional
multiturn absolute encoder
Protection
IP 54

BLDC servo motor

Small and compact – that’s the esiMot micro decentralized servo drive!
Available with PROFINET, EtherCat, and CANopen fieldbus interfaces.
esiMot M 7.1

esiMot M

Rated power
120 bis 480 W
Nominal torque
0,22 - 1,8 Nm
Motor supply
24 or 48 V DC
Optional
multiturn absolute encoder
Protection
IP 65

esiMot M “all-in-one” decentralized servo drive
 120 bis 480 W with integrated power electronics.
Digital 4Q controller, amplifier mode with analog control, positioning mode with PLC interface or fieldbus connection PROFIBUS-DP, PROFINET, EtherCAT, CANopen or RS485 each galvanically isolated.

esiMot XL

Rated power
0,78 - 1,21 kW
Nominal torque
2,2 - 5,8 Nm
Motor supply
230 or 400 V AC
Optional
multiturn absolute encoder
Protection
IP 65

Absolute position detection in the esiMot XL decentralized servo drive!

The brushless drive offers a high degree of variability thanks to the available inputs and outputs and its versatile functionality.
Available with the fieldbus connections PROFIBUS-DP, PROFINET, EtherCAT and CANopen.

esiMot SL

Rated power
3,1 - 4,4 kW
Nominal torque
10 - 20 Nm
Motor supply
400 V AC
Optional
multiturn absolute encoder
Protection
IP 65

The all-in-one brushless servo drive with integrated electronics and three-phase 400 V power supply offers a high degree of variability and good integration capability.
Available with the fieldbus connections PROFIBUS-DP, PROFINET, EtherCAT and CANopen.
