DM6
Description
DM6 LED display module
14 mm, 6-digit LED display for industrial applications
The DM6 display is available with the fieldbus interfaces PROFIBUS-DP, PROFINET, CANopen, EtherCAT or RS485 connection.
PROFIBUS / PROFINET data and values are converted and displayed. This display module contains an integrated character set and can display signed numbers. Individual segments can be easily controlled. With the built-in flashing function for all or individual points, it is possible to effectively indicate when limit values are exceeded or alarm statuses. Many other useful functions are available. The display module is therefore suitable for displaying any process data such as pressure, flow rate, positions, temperature, quantity, speed, counter values, etc. in production systems and manufacturing machines.
- Flashing function for all or individual locations
- LEDs in 2 colors: red or green, 6 digits, 14 mm digit height
- 5 m reading distance
- For ambient temperature: 0 … 50°C
- Possible fieldbus interfaces: PROFIBUS, PROFINET, EtherCAT, CANopen, RS485
- IP64 protection rating when installed vertically on the front (resistant to splashing water from all sides, but not to water jets)
- Optional flexible transparent protective cover available for front sealing (enabling protection up to IP65)
Analog/counter:
- Display of analog values 0 – 10 V, 0/4 – 20 mA
- 20 bit resolution
- Scalable display value
- Up / down counter, 3 digital inputs 24 V, 25 kHz
Dimensions:
- According to DIN 43700, mounting cutout 45 x 92 mm
